DRA Harmony

Rising in a kind of quiet glory over the rapidly evolving corridor of Chennai, DRA Harmony by DRA Homes is set in Navalur, Chennai, and it feels very much like a premium high-rise pocket for urban living that is a bit more sophisticated than average. It stands tall across 13 floors, and inside, there’s an exclusive development with a close-knit vibe, only 143 premium apartments in total. The layouts are meticulously planned 3 BHK options in the range of 1,409 to 1,418 sq. ft., so you get enough room for personal time, better cross-ventilation too, and of course, wide panoramic glimpses of the city’s thriving skyline.

Day-to-day life at DRA Harmony in Navalur kind of seems to circle wellness, rest, and recreation, and that small, easy peace of mind that people keep chasing after. You can keep up with an active routine at the fully equipped gymnasium, or swing for a friendly match at the indoor badminton court. Kids also have their own vibrant and safe play area, not just a random corner. There’s also a grand multipurpose hall, which works nicely for family functions, celebrations, or community meetups when everyone wants to come together.

Keeping modern infrastructure in mind, plus a sustainability mindset, the property is fully guarded with a strong compound wall. Lift facilities are reliable, there’s 100% power backup, and an eco-friendly rainwater harvesting system in place. Overall, it delivers that hard-to-find balance between connectivity and a genuinely upscale kind of comfort, kind of effortless but still thoughtfully done.

SPECIFICATIONS

STRUCTURE

• Structural System : RCC framed structure designed for seismic compliance (Zone-III).

• Masonry : AAC block masonry wall.

• Pest Control : Anti-termite treatments wherever applicable during the construction stage.

FLOOR FINISH WITH SKIRTING

• Living, dining : 800mm x 800mm vitrified tile flooring and skirting.

• Bedrooms& kitchen : 600mm x 600mm vitrified tile flooring and skirting.

• Bathrooms : 300mm x 300mm anti-skid ceramic tile flooring.

• Balcony : 300mm x 300mm anti-skid ceramic tile flooring.

• Utility / service area : 300mm x 300mm anti-skid ceramic tile flooring.

WALL FINISHES

• Internal walls : Two coats of acrylic emulsion over one coat primer and two coats of wall putty.

• Ceiling : Two coats of acrylic emulsion over one coat primer and two coats of wall putty.

• Exterior walls : Plaster finish with weather proof texture paint or weather proof emulsion paint as decided by the architect

• Bathrooms : 300mm x 450mm Glazed ceramic wall tiles up to 7'-0" height.

• Kitchen : Glazed ceramic wall tile 2'-0" above the kitchen counter.

• Utility : Glazed ceramic wall tile up to 3'-0".

KITCHEN&UTILITY / SERVICE AREA

• Kitchen platform : Platform with granite counter slab 2'-0" wide at height of 800mm from the finished floor level.

• Kitchen sink : Stainless steel single bowl sink without drain board and sink faucet of Hindware / Parryware or equivalent

• Electrical point : Provision for exhaust & water purifier.

• Utility area : Provision for washing machine.

BATHROOMS

• Sanitary fixture : Wall mounted European Water Closet (EWC) of Hindware / Parryware or equivalent will be provided with concealed cistern.

• Cp fitting : Health faucet, pillar cock, wall mixer, overhead shower Hindware / Parryware or equivalent.

• Drain : SS square designed gratings will be provided.

• False ceiling : Grid type false ceiling will be provided above 7'-0" height(easy maintenance of plumbing lines & geysers

JOINERY

• Main doors : Pre-engineered veneer finish flush door with ironmongery like door lock, tower bolt, door viewer, magnetic catcher in SS finish will be provided.

• Bedroom doors : Pre-engineered laminate finish flush door with ironmongery like door lock, tower bolt, magnetic catcher in SS finish will be provided.

• Bathroom doors : Pre-engineered laminate finish flush door with ironmongery like thumb turn lock and a latch will be provided.

WINDOWS

• Windows : UPVC sliding windows with bug mesh will be provided inside the apartments (except openable windows & bug mesh protects you from the menace of mosquitoes) - (U).

• French doors : UPVC frame and sliding door with see through glass.

• Ventilators : UPVC frame of fixed or adjustable louvered or openable shutter for ODU access.

• MS Grill : MS safety grills will be provided all the sliding windows inside the apartment.

HANDRAIL

• Balcony handrails : MS handrail will be provided as per architect design

WATERPROOFING

• Water proofing : Water proofing will be done the water retain area like lift pit, toilet, balcony & utility / service area, UG sump, STP & OHT

ELECTRICAL

• Power Supply : 3 Phase connection for each apartment.

• Power back-up : 350 watts for 2BHK, 500 watts for 2.5BHK & 3BHK through Automatic Changeover Current & Limiter (ACCL). (Instead of pre-designed use of electrical light points during power cut flexibility to use the lighting circuit of choice within the allotted power capacity).

• Safety device : RCCB safety device will be provided for each apartment (protection against voltage fluctuations, earth fault as well as any leakage current).

• Switches & sockets : Modular Switches and sockets will be of Anchor Roma / L & T or equivalent.

• Wires : Fire Retardant Low Smoke (FRLS) copper wire of a quality ISI brand.

• TV : Provision for TV in living and master bedroom with pre-wired co-axial cable for DTH easy connectivity.

• Data : Provision for fibre optical cabling in living.

• Air-conditioner : Split air-conditioner provision will be provided living/dining and all the bedrooms. Pre - installed conduit provided as provision for A/C (Easy for fixing your air-conditioner without calling technicians to drill the walls).

• Exhaust fan : Exhaust fan provision for all the toilet.

• Geyser : Geyser provision for all the toilets.

PLUMBING

• Water supply : Hydro pneumatic Pressure System (Provides water at constant pressure in all apartment irrespective of the floor vis-à-vis traditional overhead tank) - (U).

• Internal : All internal plumbing line are CPVC.

• External : All external plumbing lines are UPVC / PVC pipes.

• Drainage : All drainage plumbing lines are PVC pipes.

Colleges

• Agni College of Engineering - 2 kms

• Sathyabama University - 4 kms

Transports

• Thalambur Junction - 800 meters

• Navalur Junction - 2 kms

Entertainment & Shopping

• The Marina Mall - 2.8 kms

DRA Homes has established itself as a reliable real estate developer that provides exceptional services to its clients throughout four decades of operational success. The company has established a trustworthy reputation throughout Southern India because it conducts business operations in a transparent manner while delivering services that create happiness for more than 12000 families through its complete project delivery system which delivers projects on schedule and meets high construction standards.

DRA has built its business operations through diversified portfolio management which enables customers to achieve their home ownership goals. DRA provides its customers with two options because they need either a modern apartment that uses V-Design principles to create open spaces or light-filled areas or a complete villa that provides them with exclusive outdoor peace. DRA offers customers multiple high-value properties which include complete title rights and high potential asset appreciation, plus land buying opportunities in prime areas that enable customers to build their own residences.

DRA Homes establishes its unique identity through its commitment to building long-lasting value, which continues beyond the first purchase. DRA Homes maintains their attractive and healthy community spaces through their use of sustainable building methods and high-quality construction materials, and their effective management of real estate. DRA Homes created a foundation that will generate everlasting moments through its four decades of home construction experience, which embodies its core values of integrity and professional excellence.
